FUNCTIONALITY
AND USE
FUNCTIONALITY
AND USE
The RSE is a professional stone burier designed to tackle tough conditions while ensuring outstanding reliability and performance.
One of the widest under-frame clearances in the range allows the machine to operate efficiently even in high stone-density soils, minimizing friction and, consequently, reducing the effort required from the tractor, resulting in significant energy savings.
The RSE excels in the most demanding conditions, delivering consistent and superior performance compared to its competitors, positioning itself as one of the best solutions for soil preparation.
With working widths up to 300 cm and compatibility with tractors from 80 to 160 HP, the RSE is perfect for large-scale open-field applications.
Its versatility and ability to work at depths of up to 28 cm make it essential for modern farms seeking reliability and top-quality results.
Key features that make the difference
Standard equipment:
Standard equipment:
– Universal 3-point linkage cat. 2 – 3
– Frontal linkage fixed/swinging cat. 2°–3°
– Double frame made of high-strength steel
– Single-speed central gearbox, PTO 540 rpm
– Single side transmission by chain ASA 140 HE
– Rotor bearing support with amphibious mechanical seals
– Ø 560 mm rotor with S700 steel flanges
– Rotor speed 252 rpm
– ROTOSTONE-type blades (Flat 90×12 mm)
– Double flange kit
– Heavy Duty SKF reinforced spherical roller bearings
– Selection grill with independent springs and hand crank adjustment
– Anti-wearing rods for side plates protection
– Articulated levelling bar kit with hand crank adjustment
– Ø 480 mm expanded metal roller kit with internal spiral
– Cardan drive shaft with safety bolt, 1”3/8 Z6
– Anti-wearing rods for side plates protection
– Safety devices according to EU regulations
The choice of the rotor
Rotostone rotor:
The Rotostone rotor is the ideal solution for working stony soils, thanks to its spade-shaped hoes and reverse rotation with respect to the tractor’s forward movement. This system lifts and separates stones, hard clods, and plant residues, projecting them onto a selection grill that deposits them deeper into the soil, while the finely tilled soil remains on the surface, ready for sowing. The hoes can handle even large stones, ensuring a clean, well-drained seedbed ideal for high-quality crops. Robust and versatile, the Rotostone guarantees excellent performance even on challenging soils, making it a reliable ally for every agronomic need.
Frangiter rotor:
The Frangiter rotor represents a technological advancement in soil tillage, specifically designed for clayey, compact, and hard-to-manage soils. Its aggressive yet controlled action is ensured by sharp, angled hoe blades with a blade-like geometry, which break clods into fine, uniform particles, creating even and high-performing seedbeds. Thanks to its exclusive design, Frangiter optimizes power transmission to the ground, reducing the load on the tractor. The result is outstanding operational efficiency, with low energy consumption and reduced machine wear. The angled flanges, engineered for optimal soil flow, prevent material buildup even in high-moisture conditions, maintaining consistent working depth and soil refinement quality—even in the most challenging soils.
Material S420
The S420 symbol identifies the use of high-strength special steel for the main structural components of the machine. This material ensures high robustness and superior resistance to deformation, even in highly stressed areas such as weld seams, guaranteeing greater durability and long-term reliability.
High ground clearance under frame
Machines bearing this label are designed with a wide clearance under the frame, allowing large stones to pass through easily, preventing blockages and ensuring a constant soil flow. Ideal for stony or wet soils, this configuration reduces material build-up between the rotor and the structure, enhancing operational continuity, productivity, and working quality even in the most demanding conditions.
Vibrating selection grill
Machines marked with this label are equipped with an independent vibrating selection grill, designed to separate stones by channeling them downward while allowing only fine soil to pass through. The dual-spring curl system ensures continuous vibration, preventing build-up and clogging, and delivering smooth, high-quality soil processing even in challenging conditions. On certain models, the working angle is adjustable to optimize performance and reduce power absorption.
Double flange
All machines bearing this label are equipped with a double flange, which enhances the strength of the connection between the blades and the rotor, improving resistance during the most demanding operations. This system reduces the risk of bolt breakage, ensuring greater robustness and operational continuity. Especially suitable for tough soils with significant obstacles, this solution increases machine reliability, reduces unexpected downtime, and extends component lifespan.
Double frame
Machines bearing this label are equipped with a reinforced double frame above the rotor, designed to increase structural rigidity, reduce flexing and deformation, and ensure long-term reliability and durability even under extreme working conditions. The optimised design ensures smooth soil flow without build-up, improving operational efficiency across all soil types. In stony ground, the double-wall structure of the hood protects the machine’s exterior and preserves its integrity, providing an additional advantage in terms of strength and longevity.
Spherical roller bearings
Machines marked with this label are equipped with spherical roller bearings, mounted on hubs and rotor supports. Designed to withstand high radial and axial loads, they provide greater reliability and durability even under heavy-duty conditions. Compared to tapered bearings, they offer 30% higher resistance and, thanks to their self-aligning capability, ensure operational stability and simplified installation without the need for preloading. A technical solution that improves work continuity and reduces machine downtime.
ASA HE chain side transmission
The ASA HE chain transmission uses reinforced roller chains with heat-treated, induction-hardened pins to ensure greater fatigue resistance and tensile strength. Ideal for heavy-duty applications and intensive work cycles, such as on heavy machinery and conveyors, this solution offers superior reliability, toughness, and durability compared to standard chains.
Welded steel housing
Machines with this label are equipped with a high-strength welded steel housing, serving both as protection and structural support for the chain transmission. The welded construction eliminates weak points, increasing lateral rigidity and durability even under heavy-duty working conditions. The cover, fitted with a Flexoil seal, ensures proper lubricant containment and protects it from dust and external agents, guaranteeing long-term efficiency and reliability.
Normalised rotor tube E355
All machines bearing this label are equipped with a normalized rotor tube, a heat treatment process that enhances the material’s mechanical properties, making it more resistant and less prone to breakage.
During normalization, the rotor tube is brought to a specific temperature and then cooled in a controlled manner. This process eliminates internal stresses and creates a more uniform metal structure, reducing the risk of deformation and failure during operation.
Floating seals
Machines marked with this label are equipped with floating seals on the rotor end hubs, an advanced sealing system designed to prevent the ingress of dust, mud, and water, even under extreme working conditions. Composed of two opposing metal rings separated by an oil film, the floating seals ensure perfect sealing, reduce wear, and effectively protect bearings and internal lubrication. The result is extended component lifespan, reduced maintenance needs, and maximum operational reliability—even in the presence of vibrations and contaminants.
Rotor hub
Machines marked with this decal are equipped with a transmission hub featuring an interchangeable shaft, designed to offer maximum reliability against impacts and mechanical stress. Its modular construction ensures operational strength and ease of maintenance: in case of damage, the shaft can be replaced quickly, reducing downtime and ensuring uninterrupted operation.
The choice of the roller
EXPANDED METAL ROLLER
The expanded metal roller is designed for seedbed preparation on light and dry soils, particularly suitable for lawns, gardens, and horticultural crops. Its lattice structure levels the soil without excessive compaction, leaving a slightly uneven surface that helps retain seeds in the event of rainfall. After passing, the soil remains soft on the surface and firm in depth, an ideal condition for uniform germination and better moisture conservation. Working depth is adjustable, either manually or hydraulically, to adapt precisely to every agronomic context.
SMOOTH ROLLER
The smooth roller ensures even compaction and precise levelling, making it ideal for vegetable sowing and plastic mulch laying. It improves transplanting efficiency, reduces evaporation, and creates a uniform surface ready for use. Working depth is adjustable, either manually or hydraulically, to adapt precisely to every agronomic context.
PACKER ROLLER
The packer roller ensures optimal seedbed preparation by combining uniform compaction, soil refinement, and operational stability. Ideal for light to medium soils, it enhances soil structure and water retention. Its wide contact surface provides stable support for the machine, while the triangular teeth effectively break surface crusts, facilitating drainage. The roller cleaner with individually adjustable steel scrapers prevents clogging, even in moist conditions. Working depth is adjustable, either manually or hydraulically, to adapt precisely to every agronomic context.
UNIVERSAL ROLLER
Designed with long welded ridges on its surface, this roller stands out for its effectiveness on all soil types, ensuring high performance in every season. Its universal configuration makes it the ideal solution to eliminate the need for seasonal rollers, providing a reliable and ready response even on sandy soils, where traditional rollers tend to jam. The enlarged ridges promote consistent rotation and improve the overall quality of soil preparation. Working depth is adjustable, either manually or hydraulically, to adapt precisely to every agronomic context.
Choice of accessory
AUTOMATIC CLUTCH PTO SHAFT
SIDE DISCS WITH ROUND SHANK
SIDE DISCS WITH SQUARE SHANK
MECHANICAL GRASS SEEDER
APV PNEUMATIC SEEDER
PLASTIC KIT FOR ROLLER SCRAPER
HYDRAULIC SIDE SHIFT
HYDRAULIC VERTICAL ROLLER ADJUSTMENT
LIGHTWEIGHT HYDRAULIC LINKAGE
HEAVY-DUTY HYDRAULIC LINKAGE
FIXED TRACK ERASER
TRACK ERASER WITH SHEAR BOLT SAFETY
TRACK ERASER WITH SPRING SAFETY
CUSTOM CONFIGURATIONS
Modelli e caratteristiche
| Model | RSE 145 | RSE 165 | RSE 185 | RSE 210 | RSE 230 | RSE 250 | RSE 270 | RSE 285 | RSE 300 |
|---|---|---|---|---|---|---|---|---|---|
| Tractor power min/max (Hp) |
80-160 | 90-160 | 100-160 | 110-160 | 120-160 | 125-160 | 130-160 | 135-160 | 140-160 |
| Working width stone burier (cm) |
145 | 165 | 185 | 210 | 230 | 250 | 270 | 285 | 300 |
| Working width roller (cm) |
185 | 205 | 225 | 250 | 270 | 290 | 310 | 325 | 340 |
| Transport width (cm) |
202 | 222 | 242 | 267 | 287 | 307 | 327 | 342 | 357 |
| Rotostone flanges |
7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 |
| Rotostone blades 4x |
28 | 32 | 36 | 40 | 44 | 48 | 52 | 56 | 60 |
| Rotostone blades 6x |
42 | 48 | 54 | 60 | 66 | 72 | 78 | 84 | 90 |
| Frangiter flanges |
9 | 10 | 11 | 13 | 14 | 16 | 17 | 18 | 19 |
| Frangiter blades 6x |
54 | 60 | 66 | 78 | 84 | 96 | 102 | 108 | 114 |
| Base configuration weight (Kg) |
1550 | 1620 | 1690 | 1750 | 1860 | 1945 | 2050 | 2090 | 2190 |
| Base configuration: 4-blade Rotostone + Levelling bar + Ø 480 mm expanded metal roller – Without side discs Side discs weight: 70 kg The data refers to the machine without optional equipment. Weights and dimensions shown in the tables are indicative and not binding. |
|||||||||
