The RSE-PLUS stone burier represents the top-tier model in the Massano range, designed to work with tractors from 120 to 240 HP. The 4-gear transmission has been engineered to optimise power management and ensure superior efficiency. Thanks to the two-stage reduction system, this configuration maintains a high input rotation speed to the machine, progressively reducing it to deliver the ideal rotor speed for soil processing, coupled with the appropriate torque. This approach ensures the rotor operates at a speed suited to the soil type and required task, optimising power transmission while minimising mechanical stress. This stone burier is a strategic choice for medium to large farms needing a robust, high-performance machine capable of delivering excellent results even under the most demanding working conditions.
Key features that make the difference
Standard equipment:
Standard equipment:
– Universal three-point linkage cat. 2°–3°
– Frontal linkage fixed/swinging cat. 2°–3°
– Double frame made of high-strength steel
– Single-speed central gearbox PTO 1000 rpm
– Single side transmission with 4 gears
– Side cardan transmission with safety bolt
– Rotor bearing support with amphibious mechanical seals
– Rotor Ø 560 mm with S700 steel flanges
– Rotor speed 258 rpm – 323 rpm
– ROTOSTONE-type blades (Flat 90×12 mm)
– Double flange kit
– Reinforced Heavy Duty SKF spherical roller bearings
– Selection grill with independent springs, crank-adjustable
– Anti-wearing rods for side plates protection
– Articulated levelling bar kit with crank adjustment
– Ø 480 mm expanded metal roller kit with internal spiral
– Central direct PTO shaft 1” 3/8 Z6
– Safety devices according to EU regulations
The choice of the rotor
Rotostone rotor:
The Rotostone rotor is the ideal solution for working stony soils, thanks to its spade-shaped hoes and reverse rotation with respect to the tractor’s forward movement. This system lifts and separates stones, hard clods, and plant residues, projecting them onto a selection grill that deposits them deeper into the soil, while the finely tilled soil remains on the surface, ready for sowing. The hoes can handle even large stones, ensuring a clean, well-drained seedbed ideal for high-quality crops. Robust and versatile, the Rotostone guarantees excellent performance even on challenging soils, making it a reliable ally for every agronomic need.
Frangiter rotor:
The Frangiter rotor represents a technological advancement in soil tillage, specifically designed for clayey, compact, and hard-to-manage soils. Its aggressive yet controlled action is ensured by sharp, angled hoe blades with a blade-like geometry, which break clods into fine, uniform particles, creating even and high-performing seedbeds. Thanks to its exclusive design, Frangiter optimizes power transmission to the ground, reducing the load on the tractor. The result is outstanding operational efficiency, with low energy consumption and reduced machine wear. The angled flanges, engineered for optimal soil flow, prevent material buildup even in high-moisture conditions, maintaining consistent working depth and soil refinement quality—even in the most challenging soils.
Material S700
The S700 symbol identifies the use of high-strength structural steel with a yield strength ≥700 MPa, ideal for components subject to heavy loads. It features high resistance to impact and wear, as well as excellent weldability, making it particularly suitable for demanding applications on stone buriers, bed former shapers, and heavy-duty agricultural machinery. The use of S700 also allows for a reduction in overall weight, improving performance, efficiency, and long-term reliability.
Vibrating selection grill
Machines marked with this label are equipped with an independent vibrating selection grill, designed to separate stones by channeling them downward while allowing only fine soil to pass through. The dual-spring curl system ensures continuous vibration, preventing build-up and clogging, and delivering smooth, high-quality soil processing even in challenging conditions. On certain models, the working angle is adjustable to optimize performance and reduce power absorption.
Double flange
All machines bearing this label are equipped with a double flange, which enhances the strength of the connection between the blades and the rotor, improving resistance during the most demanding operations. This system reduces the risk of bolt breakage, ensuring greater robustness and operational continuity. Especially suitable for tough soils with significant obstacles, this solution increases machine reliability, reduces unexpected downtime, and extends component lifespan.
Double frame
Machines bearing this label are equipped with a reinforced double frame above the rotor, designed to increase structural rigidity, reduce flexing and deformation, and ensure long-term reliability and durability even under extreme working conditions. The optimised design ensures smooth soil flow without build-up, improving operational efficiency across all soil types. In stony ground, the double-wall structure of the hood protects the machine’s exterior and preserves its integrity, providing an additional advantage in terms of strength and longevity.
Spherical roller bearings
Machines marked with this label are equipped with spherical roller bearings, mounted on hubs and rotor supports. Designed to withstand high radial and axial loads, they provide greater reliability and durability even under heavy-duty conditions. Compared to tapered bearings, they offer 30% higher resistance and, thanks to their self-aligning capability, ensure operational stability and simplified installation without the need for preloading. A technical solution that improves work continuity and reduces machine downtime.
Normalised rotor tube E355
All machines bearing this label are equipped with a normalized rotor tube, a heat treatment process that enhances the material’s mechanical properties, making it more resistant and less prone to breakage.
During normalization, the rotor tube is brought to a specific temperature and then cooled in a controlled manner. This process eliminates internal stresses and creates a more uniform metal structure, reducing the risk of deformation and failure during operation.
Side gear tansmission with 4 gears
Machines bearing this label are equipped with a 4-gear double-reduction transmission, designed to handle heavy loads with maximum efficiency. The system allows for high input speeds with reduced torque, lowering power absorption and optimizing the performance of the side PTO shafts. The final reduction produces a slow yet powerful rotor rotation, ensuring high performance without overloading the tractor—even on challenging soils.
Cast iron housing
All machines bearing this label are equipped with a cast iron housing, designed to provide maximum strength and protection for the transmission. Thanks to its excellent heat dissipation capacity, cast iron helps maintain stable lubricant oil temperatures, preventing overheating and ensuring constant and effective lubrication. In addition, its robustness and vibration-damping properties provide greater machine stability, reduce stress on the transmission, and enhance long-term reliability.
Rotor hub
Machines marked with this decal are equipped with a transmission hub featuring an interchangeable shaft, designed to offer maximum reliability against impacts and mechanical stress. Its modular construction ensures operational strength and ease of maintenance: in case of damage, the shaft can be replaced quickly, reducing downtime and ensuring uninterrupted operation.
Floating seals
Machines marked with this label are equipped with floating seals on the rotor end hubs, an advanced sealing system designed to prevent the ingress of dust, mud, and water, even under extreme working conditions. Composed of two opposing metal rings separated by an oil film, the floating seals ensure perfect sealing, reduce wear, and effectively protect bearings and internal lubrication. The result is extended component lifespan, reduced maintenance needs, and maximum operational reliability—even in the presence of vibrations and contaminants.
The choice of the roller
EXPANDED METAL ROLLER
The expanded metal roller is designed for seedbed preparation on light and dry soils, particularly suitable for lawns, gardens, and horticultural crops. Its lattice structure levels the soil without excessive compaction, leaving a slightly uneven surface that helps retain seeds in the event of rainfall. After passing, the soil remains soft on the surface and firm in depth, an ideal condition for uniform germination and better moisture conservation. Working depth is adjustable, either manually or hydraulically, to adapt precisely to every agronomic context.
SMOOTH ROLLER
The smooth roller ensures even compaction and precise levelling, making it ideal for vegetable sowing and plastic mulch laying. It improves transplanting efficiency, reduces evaporation, and creates a uniform surface ready for use. Working depth is adjustable, either manually or hydraulically, to adapt precisely to every agronomic context.
PACKER ROLLER
The packer roller ensures optimal seedbed preparation by combining uniform compaction, soil refinement, and operational stability. Ideal for light to medium soils, it enhances soil structure and water retention. Its wide contact surface provides stable support for the machine, while the triangular teeth effectively break surface crusts, facilitating drainage. The roller cleaner with individually adjustable steel scrapers prevents clogging, even in moist conditions. Working depth is adjustable, either manually or hydraulically, to adapt precisely to every agronomic context.
UNIVERSAL ROLLER
Designed with long welded ridges on its surface, this roller stands out for its effectiveness on all soil types, ensuring high performance in every season. Its universal configuration makes it the ideal solution to eliminate the need for seasonal rollers, providing a reliable and ready response even on sandy soils, where traditional rollers tend to jam. The enlarged ridges promote consistent rotation and improve the overall quality of soil preparation. Working depth is adjustable, either manually or hydraulically, to adapt precisely to every agronomic context.
Choice of accessory
AUTOMATIC CLUTCH PTO SHAFT
SIDE DISCS WITH ROUND SHANK
SIDE DISCS WITH SQUARE SHANK
APV PNEUMATIC SEEDER
PLASTIC KIT FOR ROLLER SCRAPER
HYDRAULIC SIDE SHIFT
HYDRAULIC VERTICAL ROLLER ADJUSTMENT
HEAVY-DUTY HYDRAULIC LINKAGE
FIXED TRACK ERASER
TRACK ERASER WITH SHEAR BOLT SAFETY
TRACK ERASER WITH SPRING SAFETY
CUSTOM CONFIGURATIONS
Technical features
| Model | RSE-PLUS 250 | RSE-PLUS 270 | RSE-PLUS 285 | RSE-PLUS 300 | RSE-PLUS 320 | RSE-PLUS 340 |
|---|---|---|---|---|---|---|
| Tractor power min/max (Hp) |
120-240 | 130-240 | 140-240 | 150-240 | 170-240 | 180-240 |
| Working width stone burier (cm) |
250 | 270 | 285 | 300 | 320 | 340 |
| Working width roller (cm) |
290 | 310 | 320 | 340 | 360 | 380 |
| Transport width (cm) |
307 | 327 | 342 | 357 | 377 | 397 |
| Rotostone flanges |
12 | 13 | 14 | 15 | 16 | 18 |
| Rotostone blades 4x |
48 | 52 | 56 | 60 | 64 | 72 |
| Rotostone blades 6x |
72 | 78 | 84 | 90 | 96 | 108 |
| Frangiter flanges |
16 | 17 | 18 | 19 | 20 | 21 |
| Frangiter blades 6x |
96 | 102 | 108 | 114 | 120 | 126 |
| Base configuration weight (Kg) |
2105 | 2210 | 2250 | 2340 | 2430 | 2560 |
| Base configuration: Rotostone 4-blade + Levelling bar + Ø 480 mm expanded metal roller – Without side discs Side discs weight: 70 kg Data refer to the machine without optional equipment. Weights and dimensions listed in the table are indicative and not binding. |
||||||
